Due to the high demand on a compact foot print integrated. Base on our award winning 2A3S design. We totally redesigned it to be a integrated amplifier.

Yes - this is still a limited edition, No.1 of 25
Dual-Tone Design. Light-Black Hammertone Chassis with Taupe Hammertone Bottom Plate (What the original 2A3S MK1 used 20 years ago back in 2004)
A more complicated front end / preamp stage for higher gain for integrated/direct use
Shielded input signal path and circuit for lowest noise possible and interference, as well shielded dust from going into the Alps (Japan) Volume Control
6SL7 is used over 6SN7 as it provides a higher gain setting over the 6SN7 (6SN7 provides around 670 mv for input sensitivity, but if we want higher input sensitivity, the 6SL7 with just 330 mv is the better choice)
Triode Lab Proprietary Output Transformers for 2A3 , 8 Ohms Output, Made in Canada
Mundorf Germany M-Lytic 100uf + 100uf Hi-Fi Grade Main Power Supply ECAP
Mundorf Germany Audiophiler ZN Coupling Caps
Hammonds Canada Choke Transformer (Over Sized)
Hammonds Canada 2A3 Power Transformer with Universal Voltage
CMC RCA Gold Input Jacks and CMC Speakers Binding Post
Furutech Japan Gold AC INLET
Operation / Mode : Class A Auto-Bias
Single Ended Triode Power Amplifier
Design / Hand-Built in Canada

TRIODE LAB
